Mã sản phẩm: FLUKE F51-II/F52-II/F53-IIB/F54-IIB

FLUKE 52-II
80PK-1 standard thermocouple
FLUKE 53-IIB
FLUKE 54-IIB
FLUKE 51-II

Tình trạng sản phẩm:

Fluke 50 Series II Thermometer

Fluke FLUKE 51-II/FLUKE 52-II/FLUKE 53-IIB/FLUKE 54-IIB Thermometer
The rugged Fluke 50 II series of new contact hand-held thermometers provide fast response and laboratory accuracy (0.05% + 0.3°C).

Fluke 50 II Series Features

Minimum, maximum, and average values with relative time stamps, providing a time reference for the main event
Electronic compensation compensates for thermocouple errors and maximizes overall accuracy
Measuring J, K, T and E type thermocouples
The unit of reading can be oC, oF or Kelvin (K)
Anti-leaching, dust-proof housing, impact-absorbing sheath
User-friendly front panel, easy to set up and operate
Sleep mode for extended battery life - typically 1000 hours
Replace the battery without breaking the calibration seal
Use the optional ToolPak accessory to hang the thermometer on any metal object (using a magnet) or on a pipe (using a nylon strap and buckle) to free up your hands
3-year warranty

In addition to all of the above features, the Fluke 53 II and 54 II series include the following features:

The dual display with backlight can display any combination of T1, T2 (52 and 54 models only), T1-T2 (52 and 54 models only), plus minimum, maximum or average
Supported thermocouple types are also R, S and N (a total of 7 different types)
The callback function makes it easy to observe the recorded data again on the display.
For further analysis and mapping, the infrared communication interface of the thermometer can be used to export the data to the optional FlukeView chart software.
Can record up to 500 points of measurement data, adjustable recording interval

Technical Parameters

Technical indicators

Temperature accuracy

Above -100 °C:	J, K, T, E, and N types: ±[0.05% + 0.3°C]*
	R and S type: ±[0.05% + 0.4°C]*

Below -100 °C:	J, K, E, and N types: ±[0.20% + 0.3°C]*
	T type: ±[0.50% + 0.3°C]

temperature range

Type J:	-210 °C to 1200 °C
Type K:	-200 °C to 1372 °C
T type:	-250 °C to 400 °C
Type E:	-150 °C to 1000 °C
Type N:	-200 °C to 1300 °C *
R and S type:	0 °C to 1767 °C *

Temperature scale

ITS-90

Applicable standard

NIST-175

display resolution

	0.1 °C, 0.1 K < 1000
	1°C, 1 K >=1000

Note

*	Only the Fluke 53 II B and 54 II B thermometers can measure N, R and S type thermocouples

Environmental parameters:

Operating temperature

-10 °C to 50 °C

Storage temperature

-40 °C to 60 °C

Humidity (no condensation)

	0% to 90%; 0 °C to 35 °C
	0% to 70%; 0 °C to 50 °C

Safety technical parameters

Overvoltage category

CSA C22.2 No. 1010.1 1992; EN 61010 Amendments 1,2

Agency certification

CE, CSA, TüV (pending)

Mechanical and general parameters

size

173 mm L x 86 mm W x 38 mm

weight

400 g

battery

3 AA model batteries with a typical battery life of 1000 hours

Model Name

description

Fluke 51-II

Single input digital thermometers include:

Collision protection cover
An 80PK-1 bead probe thermocouple

Fluke 52-II

Dual input digital thermometers include:

Collision protection cover
Two 80PK-1 bead probe thermocouples

Fluke 53-II/53-II B

Single input digital thermometer with data logging capabilities, including

Collision protection cover
An 80PK-1 bead probe thermocouple

The Fluke 53-II B communicates with the computer and FlukeView Forms software (FVF-SC2) via the USB port. The current Fluke 53-II model uses infrared (IR) and serial cable communication. This change makes USB communication the difference between the Fluke 53-II and the new Fluke 53-II B.

Fluke 54-II/54-II B

Dual input digital thermometers include:

Collision protection cover
Two 80PK-1 bead probe thermocouples

The Fluke 54-II B communicates with the computer and FlukeView Forms software (FVF-SC2) via the USB port. The current Fluke 54-II model uses infrared (IR) and serial cable communication. This change makes USB communication the difference between the Fluke 54-II and the new Fluke 54-II B.
