Cảm biến tải, cảm biến cân, load cell , SMOWO micro-pull pressure sensor load cell LCS-I5

  • Đăng ngày 30-01-2019 12:23:07 AM - 1015 Lượt xem
  • Mã sản phẩm: LCS-I5

  • Tình trạng sản phẩm:


    Optional range: 10kg to 2t
    Output signal: millivolt
    Force mode: two-way tension or weighing

    Technical Parameters

    Technical indicators
    Optional range 10, 20, 30, 50, 100, 200, 500, 1000, 2000 (kg)
    Safety overload 150% FS
    Ultimate overload 200% FS
    Zero output <±1% FS
    Linear <0.5% FS
    Repeatability <±0.5% FS
    Creep (30 minutes) <±0.5% FS
    Lag <±0.5% FS
    Response time <1(ms)
    Sensitivity temperature coefficient <0.015 (%FS/°C)
    Zero temperature coefficient <0.1 (%FS/°C)
    Anti-offset capability 10 (%FS)
    Rated load deformation 0.5 (mm)
    Electrical characteristics
    Recommended excitation voltage 5-12V
    Maximum excitation voltage 15V
    input resistance 410±15Ω
    Output impedance 350±5Ω
    Insulation resistance (DC 500V) >5000MΩ
    Environmental conditions
    Operating temperature -30~65°C
    Storage temperature -40~85°C
    Relative humidity 95% rH
