Tedea 1260 Single Point Load Cell
Capacity 50 - 635kg
Aluminum design
Single point 700 x 700mm Platform
OIML R60 certified
Protection class IP66
Available with UNC thread
Optional features: EEx ia IIC T4 - Hazardous area certification
Applications: Large platform scales, counting scales, food scales
Rated output (MV/V) : 2.0&lusmn;10%
Comprehensive error: 0.030 - 0.020%
Operating temperature: -30 ℃ ~ 70 ℃
Input impedance (Ω) : 415&lusmn;15
Output impedance (Ω) : 350&lusmn;3
Cable: 1.5 4- core PVC double shield Protection level: IP66
