Mô-đun giám sát cách điện hệ thống JYM-II DC

Brand: Emerson Model: JYM-II
Output current: 1 (A) Input voltage: 80-320 (V) Output voltage: 48 (V) Output power: 20 (W) Frequency
range: 45-65 (HZ) Product certification: CE Dingshihui
insulation monitor JYM-II (horizontal),
JYM-IIA (vertical),

Product overview
Insulation tester JYM-II is one of the power supply system kits for electric power operation, which is used to monitor the
insulation status of the DC bus and each branch circuit online. Master-slave structure design is adopted, which is flexible and convenient to expand.
Product features  Can monitor two independent DC busbars, compatible with 220, 110Vdc system ·                                With  branch circuit capacitance automatic compensation function ,                              improve the measurement accuracy of ground resistance Road                                inspection    Built-in auxiliary power supply in the slave machine to realize long-distance operation of the master and slave machine Alarm                            threshold can be set to adapt to climate conditions in different regions
