Đo tốc độ YOYIK tachometer HZQS-02H turbine speed monitoring device 0-9999r/min

The tachometer HZQS-02H is used to monitor the turbine speed and impactor. Its number of teeth can be adjusted by itself, or it can be set at the factory according to customer requirements. The tachometers are all equipped with reluctance type tachometer probes. If there are no special requirements, they are all 75 in length. If there are special requirements, they can also be customized according to the actual needs of the power plant.

Technical conditions of tachometer HZQS-02H
(1) Speed ​​measurement range: 0000 ~ 9999 RPM
(2) Speed ​​detection accuracy: n ≤±1 RPM (
3) Emergency breaker striker detection speed: n>2570 RPM
(5) Alarm value: Usually set "over 1" to 3300 RPM, "over 2" to 3420 RPM. Both gears are normally open contacts; if you have special requirements, you can put them forward when ordering.
(6) Contact output capacity: AC250V 5A or DC 27V 5A
(7) Instrument power supply: AC220V 15VA
