Cảm biến áp suất, Pressure Transmitter Danfoss MBS3200
Đăng ngày 21-01-2019 05:26:44 AM - 619 Lượt xem
Mã sản phẩm: MBS3200
MBS 3200, compact pressure transmitter
The MBS 3200 compact high temperature pressure transmitter is suitable for almost all industrial applications, providing reliable pressure measurement even under harsh environmental conditions.
This flexible pressure transmitter range includes 4-20 mA, 0-5 V, 1-5 V, 1-6 V and 0-10V output signals, absolute and gauge (relative pressure) models, from 0- Measurement range from 1 to 0-600 bar and complete pressure and electrical connections.
Good vibration resistance, reliable construction, high EMC/EMI protection, and high operating temperatures make the pressure transmitter meet the most stringent industrial requirements. - 4 - 20 mA, 0 - 5 V, 1 - 5 V, 1 - 6 V, and 0 - 10 V output signals
- Operating temperature -40 to 125 ° C
- Measuring range 0 - 600 bar
- Full range of pressure and electrical connections
- Suitable for harsh industrial environments
-
-
MBS 3200 Universal High Temperature Pressure Transmitter |
model | Pressure range Bar | output signal | Pressure connection | Electrical connections | Code |
MBS3200 | 0-1 | 4-20mA | G1/2A | PG9 | 060G1870 |
MBS3200 | 0-4 | 4-20mA | G1/2A | PG9 | 060G1873 |
MBS3200 | 0-6 | 4-20mA | G1/2A | PG9 | 060G1874 |
MBS3200 | 0-10 | 4-20mA | G1/2A | PG9 | 060G1875 |
MBS3200 | 0-16 | 4-20mA | G1/2A | PG9 | 060G1876 |
MBS3200 | 0-25 | 4-20mA | G1/2A | PG9 | 060G1877 |
MBS3200 | 0-40 | 4-20mA | G1/2A | PG9 | 060G1878 |
MBS3200 | 0-60 | 4-20mA | G1/2A | PG9 | 060G1879 |
MBS3200 | 0-100 | 4-20mA | G1/2A | PG9 | 060G1880 |
MBS3200 | 0-160 | 4-20mA | G1/2A | PG9 | 060G1881 |
MBS3200 | 0-250 | 4-20mA | G1/2A | PG9 | 060G1882 |
MBS3200 | 0-400 | 4-20mA | G1/2A | PG9 | 060G1883 |
MBS3200 | 0-600 | 4-20mA | G1/2A | PG9 | 060G1884 |
-
-
-
